DVR 16 canale, Turbo HD, 4MP, PoC, Hikvision DS-7216HQHI-K2-P

Hikvision, DVR , 16 canale
Scrie o recenzie
1,198 Lei
DS-7216HQHI-K2-P
+

DVR 16 canale, Turbo HD, 4MP, PoC, Hikvision DS-7216HQHI-K2-P

Hikvision DS-7216HQHI-K2-P este un DVR Turbo HD Hikvision hibrid de 16 canale ce permite integrarea camerelor de supraveghere AHD, HDCVI, HD-TVI si CVBS. DVR-ul marca Hikvision DS-7216HQHI-K2-P permite alimentarea a 16 camere de supraveghere cu PoC (Power over Coaxial) pe o distanta de maxim 200m. Capacitatea de stocare a DVR-ului Hikvision DS-7216HQHI-K2-P este de 8TB avand 2 porturi de conectarea HDD de tip SATA. Suporta vizualizarea camerelor de supraveghere atat local cat si la distanta prin Internet de pe PC, Smartphone folosind aplicatiile dedicate (iVMS-4500).

Specificatii tehnice DVR Hikvision DS-7216HQHI-K2-P :

Audio/Video
Tehnologii suportate: HDTVI/ HDCVI / CVBS / AHD
Intrari video analogice: 16x canale
Intrari video IP: 2x canal, rezolutie pana la 4 Mp
Intrare PoC: Suporta camere Hikvision PoC
Iesiri video: 1x HDMI, 1x VGA
Rezolutie redare:

VGA: 1920x1080, 1280x1024, 1280x720, 1024x768

HDMI: 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Intrari/Iesiri Audio: 1/1 RCA
Comunicare bidirectionala: 1x canal RCA (Utilizand primul canal de intrare audio)
Inregistrare
Rezolutie inregistrare: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF
Cadre/Secunda:

Main Stream:
Cand modul 1080p Lite este dezactivat:

4MP stream:4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

3MP stream: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps

1080p stream: 1080p@15fps; 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

720p stream: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)


Sub Stream:
Cand modul 1080p Lite este activat:

4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N)

Compresie video: H.265+/H.265/H.264+/H.264
Compresie audio: G.711u
Retea
Interfata: 1x Port RJ-45 (10/100M1000M)
Protocol retea: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Utilizatori simultani: 128
Stocare
HDD: 2x port SATA, pana la 8TB (nu este inclus)
Interfete auxiliare
USB: 2x porturi USB (1 USB 2.0 , 1 USB 3.0)
RS485: 1x Port, pentru Control PTZ
Functii Speciale
Mod Backup: USB, Retea
Caracteristici generale
Temperatura de functionare: de la - 10 pana la +55 grade Celsius
Alimentare: 48 VDC
Consum: 40W
Dimensiune: 380 x 320 x 48 mm
Greutate: 2 kg
Disponibilitate:
3-5 zile

Video Recorder

Tip inregistrator
:
  • DVR
Protocoale acceptate DVR:
  • CVBS
  • CVI (HDCVI)
  • Turbo HD
  • AHD
  • IP
Numar canale video
:
  • 16 canale
Rezolutie inregistrare DVR:
  • 4MP ( 2688 x 1520 )
Numar porturi HDD:
  • 2 SATA
Numar canale audio:
  • 1 canal RCA

Fisa tehnica DS-7216HQHI-K2-P (Fisa_tehnica_DVR_Turbo_HD_Hikvision_DS-7216HQHI-K2-P.pdf, 851 Kb) [Download]
