Camera supraveghere video IP, 2MP, IR 30m, Hikvision DS-2CD1323G0-I

Hikvision, Supraveghere IP
289 Lei
DS-2CD1323G0-I-2.8mm
+
Suna-ma!

Camera supraveghere video IP,  2MP, IR 30m, Hikvision DS-2CD1323G0-I

DS-2CD1323G0-I este o camera de supraveghere video digitala IP, ce are o rezolutie maxima de 2 Megapixeli, oferita de un senzor de imagine 1/2.8" Progressive Scan CMOS.

Poate oferi imagini pe timpul noptii sau in conditii de iluminare scazuta, de la o distanta de pana la 30 metri,Hikvision DS-2CD1323G0-I fiind dotata cu un iluminator in infrarosu cu LED-uri IR.

Camera DS-2CD1323G0-I are un filtru ICR Mecanic autoretractabil ce filtreaza lumina in infrarosu pe timpul zilei, pentru a evita anumitele defecte de afisare a culorilor, iar pe timpul noptii acesta este retras pentru a permite luminii in infrarosu sa treaca, imbunatatind vizibilitatea camerei in modul alb/negru.

Functia BLC (compensarea luminii din spate) cu care este dotata camera de supraveghere video HIKVISION DS-2CD1323G0-I, permite ca obiectele aflate pe un fundal foarte luminos, de exemplu, in dreptul unei ferestre sau a unei usi de acces, care in mod normal apar foarte intunecate, sa fie vizibile, insa fundalul devine suprasaturat (foarte alb).

Specificatii tehnice camera supraveghere video IP Hikvision DS-2CD1323G0-I :

Camera
Image Sensor:   1/2.8" progressive scan CMOS
Min. Illumination:   Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @ (F2.0, AGC ON)
Shutter Speed:   1/3 s to 1/100, 000 s
Slow Shutter:   Da
Auto-Iris:   Nu
Day &Night:   IR cut filter
Digital Noise Reduction:   3D DNR
WDR:   Digital WDR
Angle Adjustment:   Pan: 0° to 360°, tilt: 0°to 75°, rotation: 0° to 360°
Lens
Focal Length:   2.8 mm
Aperture:   F2.0
Focus:   Nu
FOV:   horizontal FOV 114.5°, vertical FOV 62°, diagonal FOV 135.5
Lens Mount:   M12
IR
IR Range:   Up to 30 m
Wavelength:   850 nm
Compression Standard
Video Compression:   Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG
H.264 Type:   Baseline Profile/Main Profile/High Profile
H.264+:   Main stream supports
H.265 Type:   Main Profile
H.265+:   Main stream supports
Video Bit Rate:   32 Kbps to 8 Mbps
Smart Feature-set
Region of Interest:   1 fixed region for main stream and sub-stream
Max. Resolution:   1920 × 1080
Main Stream
Max. Frame Rate:
  50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-stream
Max. Frame Rate:
  50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Image Enhancement:   BLC, 3D DNR
Image Settings:   Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
Day/Night Switch:   Auto, scheduled
Network
Alarm Trigger:   Motion detection, video tampering alarm, illegal login
Protocols:   TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
General Function:   Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
Firmware Version:   5.5.2
API:   ONVIF (PROFILE S, PROFILE G), ISAPI
Simultaneous Live View:   Up to 6 channels
User/Host:   Up to 32 users
3 levels: Administrator, Operator and User
Client:   iVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
Web Browser:   IE8+, Chrome 31.0-44, Firefox 30.0-51, Safari 8.0+
Interface
Communication Interface:   1 RJ45 10M/100M self-adaptive Ethernet port
General
Operating Conditions:   -30 °C to 50 °C (-22 °F to 122 °F), humidity: 95% or less (non-condensing)
Power Supply:   12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
Power Consumption and Current:   12 VDC, 0.4 A, max: 5 W
PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, Max: 6.5 W
Ingress Protection:   IP67
Material:   Metal & Plastic
Dimension:   Camera: Ø 110 mm × 93.2 mm ( 4.3" × 3.7")
With package: 150 mm × 150 mm × 141 mm (5.9" × 5.9" × 5.6")
Weight:   Camera: approx. 360 g (0.8 lb.)
With package: approx. 610 g (1.3 lb.)
Disponibilitate:
3-5 zile

Camere de supraveghere

Tip supraveghere video :
  • Supraveghere IP
Rezolutie :
  • 1920 x 1080 (1080P)
Infrarosu ( IR ) :
  • 30 m
Lentila :
  • Lentila Fixa
Caracteristici speciale:
  • PoE

Nici o postare găsită

Posteaza recenzie

Datasheet Hikvision DS-2CD1323G0-I (ds-2cd1323g0-i.pdf, 939 Kb) [Download]
