Radio + USB/SD/MP3 mixer amplificator TI-120MT
Radio + USB/SD/MP3 mixer amplificator cu 3 intrare balansate de microfon, 2 intarari auxiliara de linie, 1 intrare auxiliara si 1 iesire de linie, 5 zone de iesire pe difuzoare, MIC 1 cu VOX priority, incorporat chime, control de ton (Bass/inalte), telecomanda, putere 120W/70V/110V.
Specificatii tehnice TI-120MT
| Rated Power Output | 120W |
| Speaker Outputs | 70V, 100V & 4～16Ω |
| Input | MIC 1, 2, 3: 5mV 600Ω (MIC1: phone jack balanced, MIC2, 3 XLR balanced with phantom power) AUX 1, 2: 250mV/15KΩ, Unbalanced EMC: 250mV/15KΩ, Unbalanced |
| Tone | Bass: ±10dB at 100Hz, Treble: ±10dB at 10KHz |
| Frequency Response | 50Hz～15KHz (±2db) |
| S/N Ratio | MIC 1, 2, 3: 66dB，AUX 1, 2: 80dB |
| T.H.D | Less than 0.5% at 1KHz, 1/3 rated power |
| Crosstalk | MIC: 80dB; AUX 85dB |
| Muting Function | MIC 1 over other input signals with 0～30dB attenuation EMC ove all inputs except MIC 1 |
| Controls | Individual gain controls, power switch |
| Indicators | Power, output level meter, protect |
| Protection | AC fuse, shortcircuitand high temperature |
| TUNER | |
| Frequency Response | FM 87108MHzAM 5221611KHz |
| Sensitivlty | FM = 20uV AM = 6.0mV/m |
| Signal / Noise Ratio | FM = 40dB AM = 36dB |
| MP3 | |
| MP3 Freq Response | 30Hz～20KHz |
| MP3 Store Method | Download from PC (memory card 1GB) |
| MP3 Store Format | Compatible FAT12, FAT16, FAT32 |
| ELSE | |
| Power Supply | ～110V/60Hz or ～230V/50Hz |
| Power Consumption | 240W |
| Dimension | 444x421x132mm |
| Weight | 11.6Kg |
