NVR 16 canale pana la 8MP  H.265+,  Dahua NVR4216-4KS2

Dahua, NVR
713 Lei
NVR4216-4KS2
+
Suna-ma!

NVR 16 canale pana la 8MP H.265+  200Mbps 2xSATA, Dahua NVR4216-4KS2

NVR4216-4KS2 este un Network Video Recorder (NVR) de la Dahua, are 16 canale , ONVIF 2.4, SDK, CGI, GRID si cautare inteligenta, care suporta camere IP de pana la 8MP, protocoale retea HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NT, 2 porturi USB: 1xUSB 2.0 frontal pentru controlul NVR-ului cu ajutorul mouse-ului si un USB 3.0 care faciliteaza operatia de backup pe un card USB sau pe un HDD extern. Utilizatorul poate viziona pana la 16 canale simultan in timp real. Inregistrarea se realizeaza la detectie miscarii, manual, continuu sau doar in anumite intervale orare sau zile. Tehnologia 3D intelligent positioning faciliteaza controlul speed-domurilor cu ajutorul unui mouse.

Caracteristici NVR Dahua NVR4216-4KS2:


- 16 canale IP de pana la 8MP;
- Compresie video: H.265/H.264/MJPEG;
- Tehnologie ANR (Automatic Network Replenishment) - recuperarea automata a informatiilor de la camerele IP atunci cand conexiunea este instabila
- Iesiri video simultane HDMI/VGA, rezolutia maxima 1920x1080;
- Intrari alarma: 4 canale, iesiri alarma: 2 canale;
- Latime de banda: 200Mbps;
- Suporta 2xHDD pe interfata SATA de maxima 6TB/HDD;
- Standard ONVIF 2.4 - suporta camere IP si de la alti producatori;
- Temperaturi de functionare: de la -10°C pana la +55°C;
- Dimensiuni 1U: 375×281.5×56mm;
- Alimentare: DC 12V/4A, consum 6.9W (fara HDD).

NVR/Aplicatii mobile

Imaginile stocate in NVR pot fi vizualizate de la distanta atat in reteaua locala cat si prin internet cu ajutorul unui PC/Laptop, SmartPhone sau Tableta.

Pe un PC se pot vizualiza imagini de la NVR folosind browsere cum ar fi Internet Explorer sau aplicatii dedicate cum ar fi SmartPss ce se pot conecta la un nr. nelimitat de NVR-uri si/sau camere IP din diverse locatii. Aplicatii sunt disponibile atat pentru sisteme de operare Windows cat si pentru MacOS.

 SmpartPSS pentru Windows

Dispozitivele mobile pot vizualiza imaginile din NVR-urile Dahua cu ajutorul aplicatiilor:

 gDMSS pentru Android

 iDMSS pentru iOS

 DMSS pentru Windows Mobile

Specificatii tehnice Dahua NVR2104HS-P-4KS2:

System

Main Processor

Quad-core embedded processor

Operating System

Embedded LINUX

Audio and Video

IP Camera Input

16 Channel

Two-way Talk

1 Channel Input, 1 Channel Output, RCA

Display

Interface

1 HDMI, 1 VGA

Resolution

HDMI: 3840×2160, 1920×1080, 1280×1024, 1280×720

VGA: 1920×1080, 1280×1024, 1280×720

Decoding Capacity

2ch@4K 30fps, 8ch@1080P 30fps

Multi-screen Display

1/4/8/9/16

OSD

Camera title, Time, Camera lock, Motion detection, Recording

Recording

Compression

H.265/H.264

Resolution

8Mp/ 6Mp/ 5MP/ 4MP/ 3MP/ 1080P/ 1.3MP/ 720P etc.

Record Rate

200Mbps

Bit Rate

16Kbps ~ 20Mbps Per Channel

Record Mode

Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Tampering, Video Loss), Stop

Record Interval

1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec

Video Detection and Alarm

Trigger Events

Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips

Video Detection

Motion Detection, MD Zones: 396 (22 × 18),

and Tampering

Alarm input

4 canale

Relay Output

2 canale

Playback and Backup

Sync Playback

1/4/9/16

Search Mode

Time /Date, MD and Exact Search

(accurate to second), Smart search

Playback Function

Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom

Backup Mode

USB Device/Network

Third-party Support

Third-party Support

Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more

Network

Interface

1 RJ-45 Port (10/100/1000Mbps)

PoE

16 ports (IEEE802.3at/af)

Network Function

HTTP/HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, NTP, DHCP, DNS, IP Filter, DDNS, IP Search(Support  IP camera, DVR, NVS and etc.), Easy4ip

Optical Fiber Interface

N/A

Max. User Access

128 users

Smart Phone

iPhone, iPad, Android

Interoperability

ONVIF 2.4, SDK, CGI

Storage

Internal HDD

2 SATA III Ports, Up to 6 TB capacity for each HDD

HDD Mode

Single

eSATA

N/A

Auxiliary Interface

USB

2 ports (1 Rear USB2.0, 1 Front USB2.0)

RS232

1 Canal

RS485

N/A

Electrical

Power Supply

AC100V ~ 240V, 50 ~ 60 Hz

Power Consumption

NVR: <13.2W (without HDD)

PoE: Max 25.5w for single port, 130w in total

Environmental

Operating Conditions

-10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa

Storage Conditions

-20°C ~ +70°C (-4°F ~ +158°F), 0 ~ 90% RH

Construction

Dimensions(W×D×H)

1U, 375mm×327.5mm×53mm (14.8" x 12.9" x2.1")

Net Weight

2.6kg (1.76 lb) (fara HDD)

Gross Weight

4kg(3.53 lb)(fara HDD)

Certifications

CE

EN55032, EN55024, EN50130-4, EN60950-1

FCC

Part 15 Subpart B, ANSI C63.4-2014

UL

UL60950-1

Disponibilitate:
3-5 zile

Video Recorder

Tip inregistrator :
  • NVR
Numar porturi HDD:
  • 2 SATA
